Type:Ambient Air Curtain
Place of Origin:Guangzhou, P.R. China
Certification:CE, CB
Fan type:Cross flow
Airflow:1800-4800 m3/h
Packaging Details:Carton box with foam and PE bag
OEM/ODM:Available
Availability: | |
---|---|
Quantity: | |
Ambient Cross-flow model
Unique "X" series structure lead to better uniformity, therefore better effective length and distance
Classic design suitable for most applications
Powder-coated steel case with plastic blowers
Remote control, door switch and aluminum blowers are optional
RMC-W around door heated air curtain is heating by utility heating element (PTC), with our special design the air curtain is very noiseless and safe.Power can be customized from 100w to 2kw. The length in the product include 24 ", 36 inch up to be able to 80 inch. In this range you can easlily all customize for each of our clients. Application areas contain entrance of commercial area and industrial area.Such as cold room,shopping mall,hotel,etc.
CW Vertical Series | |||||||||||||
Model | Voltage(V)/ | Motor Input Power | Max Air Velocity (M/S) | Noise (dB) | Air Volume (M3/H) | Net Weight (KG) | Gross Weight (KG) | Unit Size (MM) | Carton Size (MM) | ||||
Hi | Low | Hi | Low | Hi | Low | Hi | Low | ||||||
FMC-3512-W | 220-240/50 | 260 | 180 | 11.5 | 9.5 | 57 | 55 | 2300 | 1800 | 13 | 14 | 1210×195×180 | 1260X245X245 |
FMC-3515-W | 340 | 250 | 58 | 56 | 2900 | 2200 | 15 | 16.5 | 1505×195×180 | 1550X245X245 | |||
FMC-3518-W | 420 | 330 | 59 | 57 | 3500 | 2600 | 17.5 | 19.5 | 1825×195×180 | 1875X245X245 | |||
FMC-3520-W | 500 | 410 | 60 | 58 | 4100 | 3000 | 19 | 21 | 2000×195×180 | 2050X245X245 | |||
FMC-4012-W | 220-240/50 | 360 | 260 | 14 | 11 | 73 | 71 | 3000 | 2400 | 18 | 19.5 | 1210×250×265 | 1260X285X325 |
FMC-4015-W | 470 | 340 | 75 | 73 | 3900 | 3100 | 22 | 24 | 1505×250×265 | 1550X285X325 | |||
FMC-4018-W | 580 | 420 | 77 | 75 | 4800 | 3800 | 25.5 | 28 | 1800×250×265 | 1850X285X325 |
Ambient Cross-flow model
Unique "X" series structure lead to better uniformity, therefore better effective length and distance
Classic design suitable for most applications
Powder-coated steel case with plastic blowers
Remote control, door switch and aluminum blowers are optional
RMC-W around door heated air curtain is heating by utility heating element (PTC), with our special design the air curtain is very noiseless and safe.Power can be customized from 100w to 2kw. The length in the product include 24 ", 36 inch up to be able to 80 inch. In this range you can easlily all customize for each of our clients. Application areas contain entrance of commercial area and industrial area.Such as cold room,shopping mall,hotel,etc.
CW Vertical Series | |||||||||||||
Model | Voltage(V)/ | Motor Input Power | Max Air Velocity (M/S) | Noise (dB) | Air Volume (M3/H) | Net Weight (KG) | Gross Weight (KG) | Unit Size (MM) | Carton Size (MM) | ||||
Hi | Low | Hi | Low | Hi | Low | Hi | Low | ||||||
FMC-3512-W | 220-240/50 | 260 | 180 | 11.5 | 9.5 | 57 | 55 | 2300 | 1800 | 13 | 14 | 1210×195×180 | 1260X245X245 |
FMC-3515-W | 340 | 250 | 58 | 56 | 2900 | 2200 | 15 | 16.5 | 1505×195×180 | 1550X245X245 | |||
FMC-3518-W | 420 | 330 | 59 | 57 | 3500 | 2600 | 17.5 | 19.5 | 1825×195×180 | 1875X245X245 | |||
FMC-3520-W | 500 | 410 | 60 | 58 | 4100 | 3000 | 19 | 21 | 2000×195×180 | 2050X245X245 | |||
FMC-4012-W | 220-240/50 | 360 | 260 | 14 | 11 | 73 | 71 | 3000 | 2400 | 18 | 19.5 | 1210×250×265 | 1260X285X325 |
FMC-4015-W | 470 | 340 | 75 | 73 | 3900 | 3100 | 22 | 24 | 1505×250×265 | 1550X285X325 | |||
FMC-4018-W | 580 | 420 | 77 | 75 | 4800 | 3800 | 25.5 | 28 | 1800×250×265 | 1850X285X325 |
