Type:Ambient Air Curtain
Place of Origin:Guangzhou, P.R. China
Certification:CE, CB
Fan type:Cross flow
Airflow:1250-3350 m3/h
Packaging Details:Carton box with foam and PE bag
OEM/ODM:Available
Availability: | |
---|---|
Quantity: | |
Ambient Cross-flow model
Unique "X" series structure lead to better uniformity, therefore better effective length and distance
Classic design suitable for most commercial application
Stainless steel air inlet grille, powder-coded steel case with plastic blowers
Remote control, door switch and aluminum blowers are optional
XC Supreme Series (DC motor version available) | |||||||||||||
Model | Voltage(V)/ | Motor Input Power | Max Air Velocity (M/S) | Noise (dB) | Air Volume (M3/H) | Net Weight (KG) | Gross Weight (KG) | Unit Size (MM) | Carton Size (MM) | ||||
Hi | Low | Hi | Low | Hi | Low | Hi | Low | ||||||
FM-3509-XC | 220-240/50 | 180 | 130 | 11 | 9 | 54 | 52 | 1500 | 1250 | 11 | 12.5 | 900×232×215 | 950X275X285 |
FM-3512-XC | 260 | 180 | 57 | 55 | 2150 | 1750 | 13 | 15 | 1210×232×215 | 1260X275X285 | |||
FM-3515-XC | 340 | 250 | 58 | 56 | 2750 | 2250 | 15 | 17.5 | 1505×232×215 | 1550X275X285 | |||
FM-3518-XC | 420 | 330 | 59 | 57 | 3350 | 2750 | 19 | 22 | 1825×232×215 | 1875X275X285 |
Ambient Cross-flow model
Unique "X" series structure lead to better uniformity, therefore better effective length and distance
Classic design suitable for most commercial application
Stainless steel air inlet grille, powder-coded steel case with plastic blowers
Remote control, door switch and aluminum blowers are optional
XC Supreme Series (DC motor version available) | |||||||||||||
Model | Voltage(V)/ | Motor Input Power | Max Air Velocity (M/S) | Noise (dB) | Air Volume (M3/H) | Net Weight (KG) | Gross Weight (KG) | Unit Size (MM) | Carton Size (MM) | ||||
Hi | Low | Hi | Low | Hi | Low | Hi | Low | ||||||
FM-3509-XC | 220-240/50 | 180 | 130 | 11 | 9 | 54 | 52 | 1500 | 1250 | 11 | 12.5 | 900×232×215 | 950X275X285 |
FM-3512-XC | 260 | 180 | 57 | 55 | 2150 | 1750 | 13 | 15 | 1210×232×215 | 1260X275X285 | |||
FM-3515-XC | 340 | 250 | 58 | 56 | 2750 | 2250 | 15 | 17.5 | 1505×232×215 | 1550X275X285 | |||
FM-3518-XC | 420 | 330 | 59 | 57 | 3350 | 2750 | 19 | 22 | 1825×232×215 | 1875X275X285 |
